KNIPEX eCrimp Mechanical Crimp System Pliers for Exchangeable Crimping Dies 97 43 E

KNIPEX eCrimp Mechanical Crimp System Pliers for Exchangeable Crimping Dies 97 43 E

97 43 E KNIPEX eCrimp
Strong electromechanical drive, no hydraulic components, no leakages. Suitable for all crimping dies 97 49 XX as well as more than 1000 special crimping dies and locators for the mechanical Crimp System Pliers (97 43 200). Ergonomically optimised, user-friendly working height during workshop operation. LED working light for targeted illumination of the crimping area. Low noise level. Long servicing intervals (up to 25,000 crimping actions)! The KNIPEX eCrimp is designed to only require servicing after 25,000 crimping actions. This means the intervals between servicing the electromechanical crimping pliers is 2.5 : 1 in relation to conventionally actuated crimping pliers. The pliers are therefore available for crimping use for considerably longer. They do not need to be sent away frequently for servicing. High availability without downtimes while being serviced Powerful Li-ion rechargeable battery (12 V; 2.0 Ah; 18 Wh); charge time approx. 30 min; no memory effect. Tether attachment point to prevent falling during field work. Max. pressing force of the jaws approx. 11 kN. Approx. 170 operating cycles for plug-in connectors with 10 mm² nominal size with a single battery charge. with euro plug.

Connector socket: CEE 7/16

Mains voltage: 230 V

Mains frequency: 50 Hz

Technical Information:

• Strong electromechanical drive, no hydraulic components, no leakages
• Suitable for all crimping dies 97 49 XX as well as more than 1000 special crimping dies and locators for the mechanical Crimp System Pliers (97 43 200)
• Ergonomically optimised, user-friendly working height during workshop operation
• LED working light for targeted illumination of the crimping area
• Low noise level
• Long servicing intervals (up to 25,000 crimping actions)! The KNIPEX eCrimp is designed to only require servicing after 25,000 crimping actions. This means the intervals between servicing the electromechanical crimping pliers is 2.5 : 1 in relation to conventionally actuated crimping pliers. The pliers are therefore available for crimping use for considerably longer. They do not need to be sent away frequently for servicing. High availability without downtimes while being serviced.
• Powerful Li-ion rechargeable battery (12 V; 2.0 Ah; 18 Wh); charge time approx. 30 min; no memory effect
• Tether attachment point to prevent falling during field work
• Max. pressing force of the jaws approx. 11 kN
• Approx. 170 operating cycles for plug-in connectors with 10 mm² nominal size with a single battery charge
• No memory effect
• Tether attachment point to prevent falling during field work

Downloadable Files:

• Data Sheet: View Here
